DSJ-180 Rubber Belt Cable Puller Winch 700KGS 8m/min

Name: DSJ180 Rubber Belt Cable Puller Winch 700KGS 8mmin
Brand: XINYA
Price: 1 USD

China DSJ-180 Rubber Belt Cable Puller Winch 700KGS 8m/min factory

Place of Origin : Jiangsu, China

Brand Name : XINYA

Model Number : DSJ180/150

MOQ : 1

Price : $1,200-1,500

Weight : 150 kg

Pulling speed : 8 m/min

Electric motor : 2*1.1 KW

Cable diameter : 30-180 mm

Line pulling : 700 KGS

Model type : DSJ-180

Oversize dimension : 1020*590*400 mm

Transmission ratio : I=60

Rubber sheet thickness : 25 mm

Motor power : 1.5KW * 2

Max cable diameter : 200 mm

Pulling capacity : 900 KGS

Pulling speed range : 6 m/min

Weight range : 180-200 kg

Transmission type : Rubber belt

Contact Now

DSJ-180 Rubber Belt Cable Pulling Machine Cable Puller Winch

Application

DSJ Small Volume Cable Conveyor Belt which we manufactured, is the ideal machine of cable transmission used in power,petroleum, chemical, industrial construction, power plant extension, substation and city network transmission cable.

It is suitable for cable trays in any form of channel, cable pipe, conveying a variety of power cable and control cable.

Features

1)Using this kind of this device changes the manual transmission cable

2)It can save a lot of labor, improve working conditions

3)reduce labor intensity

4)improve work efficiency

5)ensure the safety

Quality Control

We have the complete production equipments and professional production team to manage the whole process from production to packing shipment.All products will 100% test before delivery to ensure the quality.

Our Values

1,Take First-Class Quality as Target and First-class Service.

2,As Responsibility, To Succeed By Scientific Management.

3,Customer in Heart, Quality in Hand, Technology in the Lead.

Technical Data of DSJ Small Volume Cable Conveyor Belt

Model Type	DSJ-150	DSJ-180
Line pulling(KGS)	700	900
Pulling Speed(m/min)	8	6
Electric motor	1.1KW *2	1.5KW * 2
Oversize dimension	950500400	1020590400
Weight(KG)	150	180-200
Cable diameter	Φ30 - 180 mm	Φ30 - 200 mm
Transimission	I=45	I=60
Rubber sheet thickness	25mm	25mm
